Industrial
Homogenizer
Homogenizer
Features
●
The B-500 homogenizer is the ideal solution for dispersing,
homogenizing, mixing and grinding biological tissue samples (cells,
animal and plant tissues), pharmaceutical products, cosmetics and food
products. The WT500 is characterized by a high versatility that makes it
unique on the market. A “Quick Lock” single quarter turn assembly shaft
can be combined with a wide selection of stator and rotor
configurations according to the specific application for which it is to
be used. Flexible, easy-to-use, rapid and user-friendly stator and rotor
interchangeability: a single instrument for a wide range of uses that
ensures excellent performance and safety.
Specifications
| model | B-500-A | B-500-B | B-500-D |
| Voltage/ Frequency | 220-240V/50-60Hz | ||
| Power input/output(W) | 500 | 1050 | |
| speed range(rpm) | 10000~30000rpm | 4000~26000rpm | |
| Rotor speed(m/sec) | 27m/sec | 47m/sec | |
| Speed Setting | 7 speeds | 100rpm step adjustable | |
| Time Setting | - | 1~999min | |
| Range(ml,H2O) | 100ml-5,000ml (Shaft B-500/25G) | 100ml-5,000ml (Shaft B-500/25F) | 0.2~10000 |
| Max viscosity(mPas) | 10,000mPas | ||
| Material | stainless steel PTEE | ||
| Weight(kg) | 9kg | 6.5kg | |
| Dimensions(mm) | 70x70x255 | 90×90×365 | |
| noise emission(drive only) | 79dB(A) | ||
| Operating Environment | 0-40℃ , 85%rel.humidity | ||
| Protection class | IP20 | ||
![250G1154940344[1].png](/static/upload/image/20260426/1777165735120201.png)
